KNX Dimming Actuator 4-fold, 4SU MDRC, 1-10 V, RGBW. Control device for 1-10 V electronic transformers with relays. Current max. 16 A, capacitive load max. 140 μF. Push Button for manual operation and indicator for each channel. To control 1-10V electronic transformers (ECG). With RGBW functionality. RGB und HSV control with extensive colour functions. Offers control voltage up to 30 ECG (each channel). Voltage reversal protection. Embedded switching relays for 30 ECG / 30 W, 20 ECG / 58 W, 15 ECG / 2x36 W, 10 ECG / 2x58 W. Adjustable switch-on behaviour. Minimum/maximum brighness value adjustable. Adjustable dimming speed. Central switching functions. 8 scenes per channel. 1 Bit automatic function. 3 year warranty.

KNX IP Interface with IP Secure and Data Secure, 2SU MDRC, with email and time server functions. To enable bidirectional communication between PC and the KNX bus via TCP/IP. 4 simultaneous connections possible. Programming the KNX bus via TCP/IP. Power supply by KNX bus, no external bus power supply required. Encrypted transmission at sending emails. Time server functions to send time and date on the KNX bus. Supports extended group addresses. KNX IP Secure and KNX Data Secure (from ETS 5.7). Secure access to the KNX bus through IP Secure with security key. Firmware can be updated. Quick application download (long frame support for ETS5). 3 year warranty.

KNX Shutter Actuator 4-fold, 4SU MDRC, 8 A, 230 V AC. For 230 V AC shutter motors up to 300 W. With sun position calculation. Comprehensive application. Lockable manual operation and LED indicator for each channel. Operation mode blind/shutter. Practical ventilation function (window open/tilt). Automatic sun shading/slat adjustment with sun position calculation. Travel-, pause-at-change-of-direction and step time adjustable. Separate travel time for up and down adjustable. Tip operation for accurate positioning. Extended 1 Bit automatic positions and logical functions. 1 Byte absolute positioning for shutter and blinds. Alarm, central- and block functions. Behavior after alarms and locking separately configurably. Priority/forced operation with automatic release time. Adjustable behavior in case of bus voltage failure/return. Two contacts share one L-connection. Quick application download (long frame support for ETS5). 3 year warranty.

KNX Bus Power Supply, 4SU MDRC, 640 mA. With additionally choke free output.Nominal current 640 mA, continuous current 960 mA, peak 1200 mA. KNX power supply with integrated choke. Mains voltage 230 V AC. Short-circuit-proof. Overload safe. Temperature control with shutdown at over temperature. LED indicator for bus reset, normal operation and bus overload. 3 year warranty.

KNX Universal Actuator 6-fold, 4SU MDRC, 16 A, 230 V AC, 100 μF, 15 ECG. Compact design with bistable relays. Current max. 16 A with ohmic load, 100 μF / 15 ECG. With sun position calculation / shading. Comprehensive function extension. Can be used as Switch Actuator (max. 6-fold) or Shutter Actuator (max. 3-fold). Mixed applications of Switch- and Shutter Actuator possible. Heating control with PWM 0-100 %. Push Button and LED indicator for each channel. Practical ventilation function (window open/tilted). Automatic shading / slat tracking with sun position calculation. Time functions (switch-on/-off delay, staircase light function). Status response (active/passive) for each channel. Logical linking of binary data, 8 scenes per channel. Central switching functions and block functions. Operation mode blind/shutter adjustable. Running, pause and step time freely adjustable. Adjustable behavior in case of bus voltage failure/return. 4 mm² / 2x2,5 mm² connection terminals. Separate L-connections. 3 year warranty.

Fläktkonvektor för 2- eller 4-rörsenhet med 2-punktsventiler eller 3-punktsventil och upp till tre fläkthastigheter, för DIN-skena (4,5 enheter). Den innehåller 2 oberoende utgångar 16 A C-Load, som kan konfigureras som individuella utgångar eller som en slutarkanal. Dessutom har den 6 analog-digitala multifunktionsingångar som kan konfigureras som binära ingångar för sensorer och potentialfria tryckknappar, som temperatursondsingångar eller som rörelsesensoringångar. Den inkluderar Master Light-funktion, 10 logiska funktioner och tillåter manuell styrning av utgångarna med statusindikering via lysdioder. Tillbehör: temperatursond och rörelsesensor.

Multifunktionsställdon för DIN-skena (4,5 enheter) med 8 utgångar (16 A C-Load) som erbjuder flera konfigurationer som slutarkanaler, som individuella utgångar eller som block av 2-rörs fläktkonvektorstyrning. Den tillåter manuell kontroll av dess utgångar genom tryckknapparna på locket. Den innehåller 20 oberoende logiska funktioner. Den är kompatibel med KNX Secure. Tillbehör: AC/DC slutaradaptrar.

KNX Shutter Actuator 4-fold, 4SU MDRC, 8 A, 24 V DC. For 24 V DC shutter motors up to 180 W. With sun position calculation. Lockable manual operation and LED indicator for each channel. Operation mode blind/shutter. Practical ventilation function (window open/tilt). Automatic sun shading/slat adjustment with sun position calculation. Travel-, pause-at-change-of-direction and step time adjustable. Separate travel time for up and down adjustable. Tip operation for accurate positioning. Extended 1 Bit automatic positions and logical functions. 1 Byte absolute positioning for shutter and blinds. Alarm, central- and block functions. Behavior after alarms and locking separately configurably. Priority/forced operation with automatic release time. To feed 24 V DC motors with 2 connections. Integrated commutator circuit. Adjustable behavior in case of bus voltage failure/return. Quick application download (long frame support for ETS5). 3 year warranty.

KNX långa ramar / bussdriven / 1 modul bredd (18 mm).

KNX värmeställdon med utgångar för styrning av värme eller kyla (på/av eller PWM), oberoende intern temperaturregulator. KNX K4 ställdon har interna temperaturregulatorer och utgångskanaler för styrning av värme- eller kylsystem. Temperaturregulatorerna kan styra både de 4 utgångarna på KNX K4 och andra klimatsystem på KNX-bussen. I automatiskt läge är temperaturregulatorerna inställda på nominella temperaturer för olika lägen. På så sätt är det enkelt att växla mellan lägena, komfort, standby, eko och byggnadsskydd. Omkopplingen görs via ett objekt, t.ex. via en manuell omkopplare, kopplingsur eller sensoromkopplarutgångar i KNX-systemet. Knapparna på enheten möjliggör direkt manuell omkoppling av de anslutna systemen. Lysdioder visar om utgångskanalen styrdes manuellt eller körs i automatiskt läge.

KNX Switch Actuator 4-fold, 4SU MDRC, 16/20 A, 230 V AC, C-load, industrie, 200 μF. Switch Actuator with bistable relays, for heavy C-loads. Current max. 16/20 A, capacitive load max. 200 μF. Comprehensive function extension. Mechanical manual operation for direct actuation of the relay contact, status visible. NO and NC contact operation. Time functions (switch-on/switch-off delay). Extensive staircase light and impulse functions. Extended logical and scene functions for each channel. Extended status functions (inverted, cyclic, at block). Treshold switch (Byte/2 Byte/2 Byte float). Hour meter for switching. Priority/forced operation with automatic release time. 4 mm² / 2x2,5 mm² screw terminals. Separate supply phases. Power supply via KNX bus. Quick application download (long frame support for ETS5). 3 year warranty.

KNX Switch Actuator 4-fold, 4SU MDRC, 16 A, 230 V AC, C-load, standard, 140 μF, current measurement. Standard version with bistable relays.
Comprehensive application. Integrated True RMS current measurement. Current measurement range 10 mA to 16 A. Integrated energy consumption meter function (Wh/kWh). Fast reaction <1s at Master/Slave operation. Push Button for manual operation and LED indicator for each channel. Time functions (switch-on/switch-off delay, staircase light function). Threshold switch function and Consumption threshold value. Logical linking of binary data, 8 scenes per channel. Operating hours meter. Extended status functions (inverted, cyclic, when locked). Priority / forced operation with automatic release time. Adjustable behaviour on bus voltage failure / -return. All L-connections separated, 4 mm² / 2 x 2,5 mm² connection terminals. 3 year warranty.

KNX Switch Actuator 8-fold, 4SU MDRC, 16 A, 230 V AC, compact, 70 µF, 10 ECG. Compact Switch Actuator with bistable relays. Current max. 16 A with ohmic load, 70 μF / 10 ECG. Function extension. Lockable manual operation and LED indicator for each channel. NO and NC contact operation. Status response at manually operation. Time functions (switch-on/switch-off delay). Extensive staircase light and impulse functions. Status response (active/passive) for each channel. Logical linking of binary data. Extendend scene functions for each channel. Central switching functions and block functions. Adjustable behavior in case of bus voltage failure/return. Separate L-connections. Power supply via KNX bus. Quick application download (long frame support for ETS5). 3 year warranty.

KNX LED Controller 4-channel, 4/8 A, RGBW, 4SU MDRC. Suitable for 12/24 V CV LED, 4 separate channels or RGBW, TW. Comprehensive application. Absolute and relative dimming for HSV colour space and RGB. Tunable White colour temperature control. Selectable dimming curve and PWM frequency up to 1000 Hz. Global and individual dimming speeds. Individual and predefined sequences (e.g. TV Simulator). Repetition of sequences for automatic colour control. Suitable for 12/24 V CV LED (Common Anode). Selectable load distribution: 4 channels each 4 A or 1 channel 7 A and 3 channels each 3 A. Parallel operation of 2 channels with 8 A. Operating modes: 4 x White, RGB, RGBW, Tunable White. Automatic colour temperature control Dim2Warm. Dynamic daylight control HCL.(Human Centric Lighting). Automatic time dependent dimming. Day/Night function. Overcurrent and overtemperature supervision. Intelligent 16 A C-Load relay output to control external.LED power supply. 3 year warranty.

Multifunktionsställdon. 6 utgångar x 16A C-Load och 6 ingångar. Multifunktionssensorställdon för DIN-skena (4,5u) som erbjuder flera konfigurationer av upp till 3 slutarkanaler eller 6 oberoende utgångar på 16A, som alla stöder kapacitiva belastningar. Den tillåter manuell kontroll av sina utgångar tack vare tryckknapparna på locket. Den innehåller 10 oberoende logiska funktioner. Dessutom har den 6 analog-digitala ingångar som kan konfigureras som binära ingångar för sensorer och potentialfria tryckknappar, som temperatursondsingångar eller som rörelsesensoringångar. Fyra rumstermostater för att styra värme-/kylasystem ingår.

Multifunktionssensorställdon för DIN-skena (4,5 enheter) med 6 utgångar (16 A C-last) som erbjuder flera konfigurationer som slutarkanaler eller individuella utgångar. Den tillåter manuell kontroll av dess utgångar genom tryckknapparna på locket. Den innehåller 10 oberoende logiska funktioner. Dessutom innehåller den 6 analogdigitala ingångar som kan konfigureras som binära ingångar för sensorer och potentialfria tryckknappar, som temperatursondsingångar eller som rörelsesensoringångar. Fyra rumstermostater för att styra värme-/kylasystem ingår. Den är kompatibel med KNX Secure. Tillbehör: temperatursond och rörelsesensor.

Multifunktionsställdon. 6 x 10A utgångar. 2 st DIN-skena enheter. ACTinBOX MAX6 är ett multifunktionsställdon som ger upp till 3 konfigurerbara aktiveringskanaler. Den innehåller avancerade logiska funktioner som ger den många konfigurationsmöjligheter. Den är inte lämplig för kapacitiv belastning.

KNX Shutter Actuator 4-fold with travel time measurement. 4SU MDRC, 8 A, 230 V AC, to feed 230 V AC motors up to 300 W. With sun position calculation. Comprehensive application. Travel times are automatically measured and stored. Lockable manual operation and LED indicator for each channel. Operation mode blind/shutter. Practical ventilation function (window open/tilt). Automatic sun shading/slat adjustment with sun position calculation. Travel-, pause-at-change-of-direction and step time adjustable. Separate travel time for up and down adjustable. Tip operation for accurate positioning. Extended 1 Bit automatic positions and logical functions. 1 Byte absolute positioning for shutter and blinds. Alarm, central- and block functions. Behavior after alarms and locking separately configurably. Priority/forced operation with automatic release time. Adjustable behavior in case of bus voltage failure/return. Two contacts share one L-connection. 3 year warranty.
